Pink Aluminum Oxide

Introduction

Pink Aluminum Oxide(PA) is fused from industrial alumina in high temperature furnace, been added with the right quantity of oxidized chromium. Its hardness is close to, but toughness higher than that of White aluminum oxide.

Pink aluminum oxide (PA) is used to grind measuring and cutting tools, instruments, etc., which demand low roughness on the surface. The abrasive tools made of it feature excellent durability and high processing cleaness, which are suitable for the precision grinding of the measuring tools, lathe main shafts, instruments and apparatus parts, threading work pieces and samplers, etc.

Pink Aluminum Oxide
Pink Aluminum Oxide
Technical Data

Type

Properties

PA-LC

PA-MC

PA-HC

Al2O3

98.5%min

98.2%min

97.0%min

Cr2O3

0.2-0.45%

0.45-1%

1-2%

Na2O

0.55%max

0.60%max

0.60%max

True density

3.9g/cm3min

Bulk density

1.4-1.9 g/cm3

Main Phase

α-Al2O3

Bonded abrasives Grit

FEPA F12 – F220

Coated abrasives Grit

FEPA P12 - P220

Test standard

GB/T2044-2007, GB/T6406-2016

Packing

1000kg big bag/25kg bag/or as customer request.
